F700/700P Mitsubishi Inverter
เลื่อนดูรายละเอียดเพิ่มเติม
F700/700P Mitsubishi Inverter
รายละเอียดสินค้า
เข้าชม : 910 | สั่งซื้อไปแล้ว : 0 | Wishlist Rate : 0 เพิ่มลง Wishlist
FR-F700


The specifications of the Mitsubishi  F700 VFD make this VFD from Mitsubishi Electric an absolute must for your drive systems.  The Mitsubishi F700 inverter is built to optimize 3-phase motor control, saving energy for virtually all general purpose applications.

PRODUCT FEATURES:
Programmable Timer: Generates a signal dependent on drive operating time — useful to plan scheduled machine maintenance.

Independent RS-485 Connections: Allow serial communications and keypad operation at the same time with no options needed. F700 supports Modbus RTU as well as the standard Mitsubishi Electric protocol.

Complies with Global Standards: UL, cUL, GOST, JEM, and CE marked for use in Europe. A radio filter is included
in the drive as standard to meet European EMC levels (2nd Enviromental).

Improved Field Bus Capability: Now includes Profibus DP, Lon Works, CC-Link, DeviceNet, Metasys N2 and
Siemens FLN.

Overvoltage Avoidance: The F700 measures DC bus levels when decelerating and controls drive speed to
eliminate nuisance tripping.

Windmill Start: F700 measures residual motor slot ripple to determine both the speed and direction of rotation of a coasting motor and can swiftly and smoothly bring it under control when required – whichever way it’s spinning.

Enhanced Energy Savings: An improved version of Mitsubishi Electric’s famous energyoptimization software boosts motor efficiency to unprecedented levels and intelligently maximizes energy savings.

UL Type 1, Plenum Rated, Enclosure Designs (NEMA 1): Drive can be mounted as a stand-alone unit. Single
Phase Input: UL/cUL Listed for use with Single Phase Input supply.

Ease of Programming: Taken to higher levels with the new DU07 programming dial and FR-Configurator
programming software.

Part Number Description
FR-F720P-0.75K 3P/AC 220V/50Hz&60Hz/ 0.75Kw
FR-F720P-1.5K 3P/AC 220V/50Hz&60Hz/ 1.5Kw
FR-F720P-2.2K 3P/AC 220V/50Hz&60Hz/ 2.2Kw
FR-F720P-3.7K 3P/AC 220V/50Hz&60Hz/ 3.7Kw
FR-F720P-5.5K 3P/AC 220V/50Hz&60Hz/ 5.5Kw
FR-F720P-7.5K 3P/AC 220V/50Hz&60Hz/ 7.5Kw
FR-F720P-11K 3P/AC 220V/50Hz&60Hz/ 11Kw
FR-F720P-15K 3P/AC 220V/50Hz&60Hz/ 15Kw
FR-F720P-18.5K 3P/AC 220V/50Hz&60Hz/ 18.5Kw
FR-F720P-22K 3P/AC 220V/50Hz&60Hz/ 22Kw
FR-F720P-30K 3P/AC 220V/50Hz&60Hz/ 30Kw
FR-F720P-37K 3P/AC 220V/50Hz&60Hz/ 37Kw
FR-F720P-45K 3P/AC 220V/50Hz&60Hz/ 45Kw
FR-F720P-55K 3P/AC 220V/50Hz&60Hz/ 55Kw
FR-F720P-75K 3P/AC 220V/50Hz&60Hz/ 75Kw
FR-F720P-90K 3P/AC 220V/50Hz&60Hz/ 90Kw
FR-F720P-110K 3P/AC 220V/50Hz&60Hz/ 11-Kw
FR-F740P Series (NEW SERIES)
FR-F740P-0.75K 3P/AC 380V/50Hz&60Hz/ 0.75Kw
FR-F740P-1.5K 3P/AC 380V/50Hz&60Hz/ 1.5Kw
FR-F740P-2.2K 3P/AC 380V/50Hz&60Hz/ 2.2Kw
FR-F740P-3.7K 3P/AC 380V/50Hz&60Hz/ 3.7Kw
FR-F740P-5.5K 3P/AC 380V/50Hz&60Hz/ 5.5Kw
FR-F740P-7.5K 3P/AC 380V/50Hz&60Hz/ 7.5Kw
FR-F740P-11K 3P/AC 380V/50Hz&60Hz/ 11Kw
FR-F740P-15K 3P/AC 380V/50Hz&60Hz/ 15Kw
FR-F740P-18.5K 3P/AC 380V/50Hz&60Hz/ 18.5Kw
FR-F740P-22K 3P/AC 380V/50Hz&60Hz/ 22Kw
FR-F740P-30K 3P/AC 380V/50Hz&60Hz/ 30Kw
FR-F740P-37K 3P/AC 380V/50Hz&60Hz/ 37Kw
FR-F740P-45K 3P/AC 380V/50Hz&60Hz/ 45Kw
FR-F740P-55K 3P/AC 380V/50Hz&60Hz/ 55Kw
FR-F740P-75K 3P/AC 380V/50Hz&60Hz/ 75Kw
FR-F740P-90K 3P/AC 380V/50Hz&60Hz/ 90Kw
FR-F740P-110K 3P/AC 380V/50Hz&60Hz/ 110Kw
FR-F740P-132K 3P/AC 380V/50Hz&60Hz/ 132Kw
FR-F740P-160K 3P/AC 380V/50Hz&60Hz/ 160Kw
FR-F740P-185K 3P/AC 380V/50Hz&60Hz/ 185Kw
FR-F740P-220K 3P/AC 380V/50Hz&60Hz/ 220Kw
FR-F740P-250K 3P/AC 380V/50Hz&60Hz/ 250Kw
FR-F740P-280K 3P/AC 380V/50Hz&60Hz/ 280Kw
FR-F740P-315K 3P/AC 380V/50Hz&60Hz/ 315Kw
FR-F740P-355K 3P/AC 380V/50Hz&60Hz/ 355Kw
FR-F740P-400K 3P/AC 380V/50Hz&60Hz/ 400Kw
FR-F740P-450K 3P/AC 380V/50Hz&60Hz/ 450Kw
FR-F740P-500K 3P/AC 380V/50Hz&60Hz/ 500Kw
FR-F720 Series
FR-F720-0.75K 3P/AC 220V/50Hz&60Hz/ 0.75Kw
FR-F720-1.5K 3P/AC 220V/50Hz&60Hz/ 1.5Kw
FR-F720-2.2K 3P/AC 220V/50Hz&60Hz/ 2.2Kw
FR-F720-3.7K 3P/AC 220V/50Hz&60Hz/ 3.7Kw
FR-F720-5.5K 3P/AC 220V/50Hz&60Hz/ 5.5Kw
FR-F720-7.5K 3P/AC 220V/50Hz&60Hz/ 7.5Kw
FR-F720-11K 3P/AC 220V/50Hz&60Hz/ 11Kw
FR-F720-15K 3P/AC 220V/50Hz&60Hz/ 15Kw
FR-F720-18.5K 3P/AC 220V/50Hz&60Hz/ 18.5Kw
FR-F720-22K 3P/AC 220V/50Hz&60Hz/ 22Kw
FR-F720-30K 3P/AC 220V/50Hz&60Hz/ 30Kw
FR-F720-37K 3P/AC 220V/50Hz&60Hz/ 37Kw
FR-F720-45K 3P/AC 220V/50Hz&60Hz/ 45Kw
FR-F720-55K 3P/AC 220V/50Hz&60Hz/ 55Kw
