FUJI FRENIC-Multi Series Compact Inverters
เลื่อนดูรายละเอียดเพิ่มเติม
FUJI FRENIC-Multi Series Compact Inverters
รายละเอียดสินค้า
เข้าชม : 1005 | สั่งซื้อไปแล้ว : 0 | Wishlist Rate : 0 เพิ่มลง Wishlist



FUJI FRENIC-Multi Series Compact Inverters

Gentler on the environment
Expanded capacity range and abundant model variation
The highest standards of control and performance in its class
Optimum for the operations specific to vertical and horizontal conveyance
Simple and thorough maintenance
Simple operation, simple connection
Consideration of peripheral equipment, and a full range of protective functions
You can use an inverter equipped with functions like these
Fully compatible with network operation
Global compatibility





Previous energy saving operation functions worked only to control the motor's loss to keep it at a minimum
in accordance with the load condition. In the newly developed FRENIC-Multi Series, the focus has been switched
away from the motor alone to both the motor and the inverter as electrical products. As a result, we incorporated
a new control system (optimum and minimum power control) that minimizes the power consumed by the inverter itself (inverter loss) and the loss of the motor.

Smooth starts through the pick-up function

In the case where a fan is not being run by the inverter
but is turning free, the fan's speed is checked, regardless of its rotational direction,
and operation of the fan is picked up to start the fan smoothly.
This function is convenient in such cases as when switching instantaneously from commercial power supply to the inverter.





Equipped with the highest level CPU for its class

The highest level CPU of any inverter is used.
Computation and processing capacity is doubled over the previous inverter, improving speed control accuracy.




Shortened setting time in slip compensation control

Through "slip compensation control" + "voltage tuning,
" speed control accuracy at low speeds is improved.
This minimizes variations in speed control accuracy at times
when the load varies, and since the time
at creep speeds is shortened, single cycle tact times can be shortened.



Compatible with PG feedback control

Improved speed control accuracy improves conveyor positioning accuracy.
Positioning time can be shortened.
Improves measuring accuracy on a scale.

Model list


Part
FRN0.2E1S-2A
FRN0.4E1S-2A
FRN0.75E1S-2A
FRN1.5E1S-2A
FRN2.2E1S-2A
FRN3.7E1S-2A
FRN5.5E1S-2A
FRN7.5E1S-2A
FRN11E1S-2A
FRN15E1S-2A
FRN0.4E1S-4A
FRN0.75E1S-4A
FRN1.5E1S-4A
FRN2.2E1S-4A
FRN3.7E1S-4A
FRN5.5E1S-4A
FRN7.5E1S-4A
FRN11E1S-4A
FRN15E1S-4A
FRN0.1E1S-7A
FRN0.2E1S-7A
FRN0.4E1S-7A
FRN0.75E1S-7A
FRN1.5E1S-7A
FRN2.2E1S-7A


แสดงความคิดเห็น
ภาพสินค้า
FUJI FRENIC-Multi Series Compact Inverters
